Unified SDK for DELTACAST products under Windows, Linux and OSX

The VideoMaster SDK is a software interface to communicate with DELTACAST video cards and to design your own products and applications.

It contains drivers for most computer platforms, easy to use API (Application Programming Interface), comprehensive documentation and example source code.

Specifications

VideoMaster OEM SDK features
Description Set of libraries with C/C++ API
.NET wrapper
Multi-board/multi-process management
Video channel management Flexible buffering scheme
Easy channels synchronization
SDI features 8-bit/10-bit support
Support for 3D Stereoscopic inputs / outputs
Hardware keyer control for DELTA-key family
Flexible Input/Output streams coupling
Raw mode for full access to the SDI stream
Audio embedding/de-embedding
Ancillary & VBI data insertion/extraction
Input, Output, Read-Modify-Write working modes
Time code management
Clocking and genlock configuration
DVI/HDMI features 8-bit support
RGB to YUV color-space conversion
4:4:4 to 4:2:2 down-conversion
Optional frame rate decimation for bandwidth reduction
E-EDID Handling
ASI Features Support for bit rates from 100 kbps to 100 Mbps
Support for 188 and 204-byte TS packets
Incoming bit rate monitoring
PID filter managing up to 256 PID per input channel
Incoming packets time stamping
IP Features Video transport as per SMPTE ST-2022-6
FEC as per SMPTE ST 2022-5
Seamless protection switching as per
SMPTE ST 2022-7
Full access to ancillary data and VBI
Support for embedded audio, timecode, captions, ...
Hardware proxy downscalers
VideoMaster OEM SDK Content
General Free with any card from the SDI Cards, DVI/HDMI Cards, SFP Cards, ASI Cards and Mixed Interfaces Cards

Unified SDK for the SDI Cards, DVI/HDMI Cards, SFP Cards, ASI Cards and Mixed Interfaces Cards

Easy-to-use API for direct access to 8-10-bit digital video channels

Comprehensive programmers manual

Sample programs in source code

Full online help and support
VideoMaster software only VideoMaster can now also be purchased as a software only for IP interfacing.

Proposing an IP ingest playout solution without the need of dedicated harware, by using traditional network cards.

The first implemented standard is SMPTE ST-2022-6, and our technical teams are already on their way to further evolutions like TR-03 support.

This new software implementation allows thinking at more scalable systems. Virtualization and many other advantages.
Drivers Windows XP®, Windows Vista®, Windows 7®, Windows 8®, Windows 8.1®, 32 and 64 bits editions, workstation and server versions

Linux kernel (v2.6 or higher)

MAC OS X up to 10.10
